Can't find your Samsung TV power cord location? Our complete guide shows exactly where the power port is on QLED, Crystal UHD, Frame TV, and all Samsung models with step-by-step visuals and troubleshooting.
The Samsung TV power cord location is on the back panel, typically in the lower-left corner or center-bottom. Look for a recessed rectangular port labeled "AC IN" or marked with a power symbol (⏻).
Samsung TV Series | Power Port Location | Connection Type |
|---|---|---|
Crystal UHD (DU/CU) | Lower-left back panel | Figure-8 (C7) detachable |
QLED (Q60-Q90) | Center-bottom back panel | Figure-8 (C7) detachable |
Neo QLED 4K | Center-bottom back panel | Figure-8 (C7) detachable |
Neo QLED 8K | One Connect Box only | Via One Connect Box |
The Frame (Standard) | One Connect Box only | Via One Connect Box |
The Frame Pro (2025) | Direct to TV + Wireless One Connect | Figure-8 (C7) detachable |
Important: Frame TV and premium QLED models connect power through a separate One Connect Box instead of directly to the TV. Jump to Samsung One Connect Box Power Setup for detailed instructions.
Finding the Samsung TV power cord location frustrates more people than you'd expect. Samsung designs their TVs with recessed power ports that blend into the back panel, which looks sleek but makes setup confusing when you're staring at the back of your new TV wondering where everything plugs in.
Here's what's actually happening: Samsung uses recessed power ports for aesthetic reasons and cable protection. The power input sits flush with the back panel rather than protruding, making the TV easier to wall mount and protecting the cord from accidental damage. The downside? That recessed design means the port isn't immediately obvious.
On most Samsung TVs, you'll find the power input on the back panel in one of two locations. Crystal UHD models (including the popular DU6900 and DU7000 series) place the power port on the lower-left side, below the cluster of HDMI and USB ports. QLED models typically position the power port at the center-bottom of the back panel.
The port itself is rectangular and often labeled "AC IN" or marked with the universal power symbol. It's separate from your HDMI and USB ports, so don't mistake those smaller rectangular ports for the power input. The power port is specifically designed to accept the Figure-8 connector that comes with your TV.
Now, there's an important distinction to understand: Samsung TVs use two different power connection methods. Most models use direct power connection, where the power cord plugs directly into the TV's back panel. However, Frame TVs and certain premium Neo QLED models use a One Connect Box system, where the power cord connects to a separate hub rather than the TV itself.
If you're setting up a new Samsung TV, relocating your TV to another room, or working with a secondhand purchase that came without documentation, knowing your model series makes all the difference. When you need help with broader Samsung TV troubleshooting, understanding your power connection type is usually the first step.
The most common reason people search for their power port? They're looking at the back of the TV and only see HDMI ports, USB ports, and antenna inputs. The power port is there - it's just recessed and positioned separately from the other connections. For those going through Samsung TV setup for the first time, this initial confusion is completely normal.
Before hunting for your power port, take 30 seconds to identify your exact Samsung TV model. The power connection method varies by series, and knowing your model prevents the frustration of searching in the wrong spot.
Method 1: Check the back label
Every Samsung TV has a sticker on the back panel, usually in the bottom-left corner when viewing from behind. The model number follows a specific format like UN55TU7000, QN65Q80A, or LS03T. Write this down - you'll need it.
Method 2: Through TV settings
If your TV is already connected and working:
Press the Home button on your remote
Navigate to Settings → Support → About This TV
Your model number displays on screen
Samsung's model numbers tell you exactly what type of TV you have:
Prefix | TV Type | Power Connection |
|---|---|---|
UN | UHD/Crystal UHD | Direct power to TV |
QN | QLED/Neo QLED | Direct power (most) or One Connect |
LS | Lifestyle (Frame, Serif, Sero) | One Connect Box required |
The letter after the number indicates the model year:
A = 2021
B = 2022
C = 2023
D = 2024
E/F = 2025/2026
For example, UN65DU6900F breaks down as: UN (Crystal UHD) + 65 (screen size) + DU6900 (series) + F (2025 model). This TV uses direct power connection to the lower-left back panel.
QN75QN990F tells you: QN (Neo QLED) + 75 (screen size) + QN990 (flagship 8K series) + F (2025). This premium 8K model uses the Wireless One Connect Box system.
If you need help finding your exact model details, use a Samsung TV model number lookup to get specific information about your TV's features and power requirements.
Different Samsung TV series position their power ports in different locations. I've tested dozens of models across every current series, and here's exactly where to find the power connection on each.
Standard QLED models from the Q60 through Q90 series use a straightforward direct power connection. The power port sits at the center-bottom of the back panel, recessed into a channel that runs along the TV's lower edge.
Look for a rectangular port approximately 1.5 inches wide. It's typically positioned alone or slightly separated from the main port cluster. The port accepts the detachable Figure-8 (C7) power cord included with your TV.
Models covered:
Q60A/B/C/D/E/F
Q70A/B/C/D/E/F
Q80A/B/C/D/E/F
Q90A/B/C/D (some Q90 models include One Connect option)
After connecting power, you might want to optimize your Samsung TV picture settings to get the best image quality from your QLED display.
Neo QLED models get a bit more complicated because power connection varies by specific model and price tier.
Neo QLED 4K models (QN85, QN90 series): Most use direct power connection at the center-bottom of the back panel, identical to standard QLED TVs. The 2025 QN85F and QN90F models use detachable Figure-8 cords connecting directly to the TV.
Neo QLED 8K models (QN900, QN990 series): These flagship TVs use the One Connect Box system. There's no direct power port on the TV itself. Instead, the power cord connects to the One Connect Box, which then transmits power and signals through a single cable to your TV.
The 2025 Neo QLED 8K QN990F introduces Wireless One Connect, which transmits audio and video wirelessly via Wi-Fi 7. However, both the TV and the Wireless One Connect Box still require separate power cord connections - the wireless aspect only eliminates the need for a physical data cable between them.
After getting your Neo QLED connected and running, consider performing a Samsung TV firmware update to ensure you have the latest features and performance improvements.
Crystal UHD models are Samsung's most popular line, and they have the most consistent power port location across all variants. The power port is always on the lower-left side of the back panel when viewing from behind, positioned below the HDMI port cluster.
On the DU6900 and DU7000 series (2024-2025 models), you'll find the power port about 3-4 inches from the left edge of the TV. It's recessed into a small channel and labeled "AC IN" on most units.
Models covered:
TU7000, TU8000, TU8300
CU7000, CU8000
DU6900, DU7000, DU7900
One user on Best Buy's Q&A reported difficulty finding the power port on their DU6900 because they expected it near the other ports. The answer from Samsung confirmed: "When looking at the back of the television, the port for the cable is located on the left side, below the set of ports for various other input types."
Once your Crystal UHD is powered up, you can connect it to your network via a Samsung TV ethernet connection for the most stable streaming performance.
Here's where things work differently. The Frame TV has no direct power port on the TV itself. The panel is designed to hang flush against the wall like actual artwork, which means all connections - including power - route through the One Connect Box.
The power flow works like this:
Power cord → connects to the One Connect Box
One Connect Box → receives power and houses all your input ports
Invisible Connection cable → carries power + audio + video from the box to the TV
For standard Frame TVs (2018-2025 models with model number LS03A through LS03D), the included One Connect Box is required for the TV to function. You cannot bypass it.
The 2025 Frame Pro (LS03FW) changes things up. It introduces a Wireless One Connect Box that transmits audio and video wirelessly to the TV. However, the Frame Pro TV itself now requires a separate power cord that connects directly to the TV panel. Samsung notes: "TV and Wireless One Connect require separate power cord connections."
So the 2025 Frame Pro setup requires:
One power cord from wall outlet to the Wireless One Connect Box
One power cord from wall outlet to the TV itself
The standard 2025 Frame (LS03FA) continues using the traditional wired One Connect Box with a single cable running to the TV.
The Serif: Uses direct power connection at the center-bottom of the back panel. The power port is accessible through the back of the TV's distinctive I-beam frame design.
The Sero: This rotating TV has the power port behind the rotating mechanism, at the base of the stand. Access it from the rear of the stand assembly.
The Terrace: Samsung's outdoor TV features a weather-sealed power port on the bottom panel. It uses the same Figure-8 connector but with additional weatherproofing around the port.
For Samsung TVs from 2015-2019 (J through N series designations), power port locations varied more widely:
Some models: Lower-left side
Some models: Lower-right side
Some models: Center-bottom
A few models: Integrated (non-removable) power cords
If you have an older Samsung TV and can't find the power port, check your user manual for the specific diagram. These older models sometimes had the power port on the opposite side from current designs.
Most Samsung TVs use the same universal power cord type, which makes replacements easy to find if you've lost your original or need a longer cable for wall mounting.
The vast majority of Samsung TVs use a Figure-8 power cord, technically designated as IEC-60320 C7. The name comes from the connector's shape - it looks like a figure-8 or infinity symbol.
Technical specifications:
Connector type: IEC-60320 C7 (non-polarized)
Prong configuration: 2-prong
Voltage rating: 125V (US) / 250V (EU/UK)
Amperage rating: 10A
Wire gauge: 18 AWG (standard)
Standard lengths: 4-8 feet
The good news? Figure-8 cords are universal across brands. The same power cord that works with your Samsung TV also works with LG, Sony, TCL, and most other modern flat-panel TVs. You're not locked into buying Samsung-branded replacements.
Look at the connector end that plugs into your TV (not the wall plug end):
Figure-8 (C7): Two rounded slots in a figure-8 shape, flat cable
3-prong IEC (C13): Three slots including a ground pin, used on some older or commercial models
If your TV has a recessed rectangular port about 1.5 inches wide with two small holes, you need a Figure-8 cord. If it's a larger three-hole port similar to what you'd see on a desktop computer, you need a 3-prong IEC cord.
There's frequent confusion between the One Connect cable (also called Invisible Connection cable) and a standard power cord. They're completely different:
Power cord: Carries electricity from your wall outlet to the TV or One Connect Box
One Connect cable: A proprietary data + power cable that runs from the One Connect Box to Frame TVs and select premium models
The One Connect cable is NOT a standard power cord - you can't buy generic replacements at Amazon. If you need a longer One Connect cable, Samsung sells 5-meter and 15-meter options specifically designed for their system.
For more information about other Samsung TV connection options, check out our guide on Samsung TV USB port features and capabilities.
Connecting your Samsung TV power cord is straightforward once you've located the port. Here's the complete process with verification steps to ensure everything works correctly.
Before plugging anything in:
Verify your outlet works: Plug in a lamp or phone charger to confirm the outlet has power
Inspect the power cord: Check for fraying, cuts, exposed wires, or bent prongs
Identify your power port: Reference the model-specific locations above
Position your TV safely: If laying the TV face-down to access the back, place it on a soft surface like a blanket or carpet
Step 1: Locate the AC IN port on the back panel. It's the rectangular recessed port separate from your HDMI/USB cluster.
Step 2: Orient the Figure-8 connector correctly. The connector only fits one way - line up the rounded ends with the corresponding holes in the port.
Step 3: Insert the cord firmly until it's fully seated. The connector should sit flush with the port. If it wiggles or feels loose, pull it out and reinsert.
Step 4: Route the cord through any cable management clips on your TV stand (if applicable). This prevents the cord from being accidentally yanked.
Step 5: Connect the other end to your wall outlet. Samsung recommends connecting directly to a wall outlet rather than a power strip for your primary TV connection.
Step 6: Verify the connection by checking for the red standby light. A solid red LED at the bottom edge of your TV confirms the TV is receiving power.
If you're setting up new Samsung TV for the first time, the TV should automatically begin initial setup once power is connected and you press the power button. Once you've completed the initial setup, you can configure Samsung TV parental controls if you need to restrict content access.
Planning to wall mount? Think about power cord routing before mounting the TV:
Standard cords extend straight out from the TV, requiring 2-3 inches of wall clearance
90-degree angled cords allow the TV to sit closer to the wall (available as replacements)
In-wall rated cables are required if routing power through your wall (check local electrical codes)
For those who don't have the remote handy, our guide on how to set up Samsung TV without remote covers alternative control methods using the TV's physical buttons.
Never force the power cord connector - if it doesn't fit, verify you have the correct cord type
Avoid excessive bending near the connector on either end
Use a quality surge protector to guard against power spikes (despite Samsung's recommendation for direct outlet connection, surge protection is valuable)
Don't daisy-chain multiple power strips
One quirk worth mentioning: if your Samsung TV is connected to an external device via HDMI (gaming console, cable box, etc.), the TV may automatically turn on when that device powers up due to Samsung TV turns on by itself features like Anynet+ (HDMI-CEC). This is normal behavior, not a power issue.
Frame TV owners and those with premium Neo QLED 8K models need to understand the One Connect Box system. It's a fundamentally different approach to TV power and connectivity.
The One Connect Box is a central hub that consolidates all your TV connections - HDMI inputs, USB ports, antenna, ethernet, and yes, power - into a single external unit. Rather than running multiple cables to the back of your TV, everything connects to the One Connect Box. A single cable (the Invisible Connection) then carries all signals from the box to your TV.
The primary benefits:
Cleaner installation: Only one slim cable runs to the wall-mounted TV
Flexibility: Position the box up to 5 meters (16 feet) from the TV with standard cable, or up to 30 feet with extended cables
Future-proofing: Upgrade your One Connect Box without replacing the TV panel
Required (TV won't function without it):
All Frame TVs (2018-2026): LS03A, LS03B, LS03C, LS03D, LS03E, LS03FA
Frame Pro (2025): LS03FW (uses Wireless One Connect)
Included but TV has direct power option:
Neo QLED 8K QN900/QN990 series
Select premium Neo QLED 4K models (varies by year)
NOT used:
Crystal UHD (all models)
Standard QLED Q60-Q80 series
The Serif, The Terrace (direct power)
Understanding how power travels through the One Connect system clears up a lot of confusion:
For Standard One Connect (Frame TV, Neo QLED 8K):
Wall Outlet → Power Cord → One Connect Box → Invisible Connection Cable → TV
The power cord connects ONLY to the One Connect Box. The TV receives power through the Invisible Connection cable - there's no separate power connection to the TV itself.
For Wireless One Connect (2025 Frame Pro, QN990F 8K):
Wall Outlet #1 → Power Cord → TV
Wall Outlet #2 → Power Cord → Wireless One Connect Box
Both the TV AND the Wireless One Connect Box require separate power connections. The wireless aspect only eliminates the physical cable between box and TV for audio/video signals.
Step 1: Unbox the One Connect Box and locate the included power cord.
Step 2: Connect the power cord to the power port on the One Connect Box. The port is labeled and typically on the back of the box.
Step 3: Plug the power cord into your wall outlet.
Step 4: Connect the Invisible Connection cable to the One Connect port on the box (large rectangular port).
Step 5: Connect the other end of the Invisible Connection cable to the One Connect port on your TV. On Frame TVs, this port is in a recessed channel on the back panel.
Step 6: Connect your external devices (cable box, game console, soundbar) to the HDMI/audio ports on the One Connect Box - NOT to the TV.
Step 7: Power on - your TV should boot up and display the Samsung logo.
For connecting audio equipment through the One Connect system, our guides on how to hook up soundbar to Samsung TV and how to connect external speakers Samsung TV cover the specific port configurations. You might also want to explore your Samsung TV sound settings to optimize audio output through connected devices.
TV shows no picture despite connections being made:
Verify the power cord is connected to the One Connect Box (not just plugged into the wall)
Check that the Invisible Connection cable is fully seated at BOTH ends
Try a different power outlet for the One Connect Box
Look for the LED indicator on the One Connect Box - it shows connection status
Intermittent power or picture drops:
Ensure the Invisible Connection cable isn't kinked or bent sharply
Check for damage to the cable's connectors
Verify the cable is the correct type for your TV model year (some years have different pinouts)
No sound from connected devices:
Confirm devices are connected to the One Connect Box, not the TV
Check HDMI port assignments in TV settings
If you're experiencing HDMI-related issues through the One Connect system, our guide on how to reset HDMI ports Samsung TV may help resolve connection problems.
You've connected the power cord, but something's not right. Maybe the TV won't turn on, or there's no standby light, or you're seeing strange blinking patterns. Here's how to systematically diagnose and fix Samsung TV power issues.
The red standby light is your primary diagnostic tool for power issues. It's a small red LED at the bottom edge of your TV, near where you aim the remote.
Standby Light Status | What It Means |
|---|---|
Solid red (TV off) | TV is receiving power, ready for use |
No light | TV has no power OR TV is on with black screen |
Blinking red | Power supply issue - likely needs service |
Red light off (TV on) | Normal - light turns off when TV is in use |
Understanding these indicators is essential for Samsung TV troubleshooting and diagnosing whether you have a power issue or something else entirely.
When there's no standby light at all, your TV isn't receiving power. Work through these steps:
Step 1: Verify the outlet works Plug a lamp or phone charger into the same outlet. If it doesn't work, you've found your problem - the outlet is dead.
Step 2: Check the power cord connection at the TV Remove the power cord from the TV's AC IN port and reinsert it firmly. The connector should be fully seated without any gaps.
Step 3: Inspect the power cord for damage Look for fraying, cuts, kinks, or burn marks. Check both ends of the cord and along its length.
Step 4: Try a different outlet Skip any power strips and plug directly into a different wall outlet that you've confirmed works.
Step 5: For One Connect models - check the box first If you have a Frame TV or Neo QLED 8K, verify power is reaching the One Connect Box. The LED indicator on the box should be lit.
Step 6: Perform a power reset Unplug the TV from the wall for 60 seconds. While unplugged, press and hold the power button on the TV (not the remote) for 30 seconds. Wait another 30 seconds, then plug back in.
Still no standby light? The internal power supply may have failed. Contact Samsung Support or a qualified repair service.
The TV has power (indicated by the red standby light), but it won't respond to the remote or turn on.
Step 1: Try the TV's physical power button The button location varies by model - check the back right side, bottom edge, or under the Samsung logo. Press it directly rather than using the remote.
Step 2: Replace remote batteries Weak batteries often cause intermittent remote issues. Use fresh batteries, not ones from another device.
Step 3: Check for stuck buttons A stuck button on the remote can prevent the TV from responding normally. Inspect all buttons for debris or sticking.
Step 4: Perform a soft reset Unplug the TV for 30 seconds, then plug it back in.
Step 5: Disconnect all HDMI devices Unplug every HDMI cable from the TV (or One Connect Box). Try powering on with no devices connected.
TV still won't turn on? This likely indicates a mainboard issue requiring professional service. If you've recently experienced issues with your TV being unresponsive, you may also want to clear cache on Samsung TV after getting power restored to improve overall performance.
Sometimes a TV appears unresponsive but is actually frozen. If your Samsung TV frozen on a particular screen or application, the reset procedure above should resolve it.
A blinking red standby light typically indicates a power supply board issue. This is more serious than other problems.
Common blink patterns:
2 blinks, pause, repeat: Often indicates power board failure
Continuous slow blinking: May indicate firmware issue during boot
Rapid blinking: Usually power supply related
What to do:
Do NOT continue attempting to power on the TV - this could cause additional damage
Perform the full power reset (60 seconds unplugged, hold power button)
If blinking continues after reset, professional service is needed
If your Samsung TV keeps rebooting in a loop with the standby light blinking, this often indicates a power supply or mainboard failure that requires repair.
If the power cord you're trying to use doesn't fit the port on your TV:
Verify the connector type: Most Samsung TVs use Figure-8 (C7). If you have a 3-prong cord, it won't fit.
Check connector orientation: Figure-8 connectors only insert one way
Don't force it: Using the wrong connector type can damage the port
For One Connect models: Make sure you're connecting to the box, not looking for a port on the TV
Contact Samsung Support if:
No standby light appears after trying all troubleshooting steps
Standby light continues blinking after power reset
TV has power but won't turn on with either remote or physical button
Visible damage to the power port
You smell burning or see smoke (unplug immediately)
For issues where the TV has power but shows Samsung TV no signal, the problem is likely with your input source or HDMI connections rather than power. Similarly, if your TV is running but experiencing Samsung TV buffering or your Samsung TV so slow to respond, those are performance issues unrelated to power connection.
Lost your power cord during a move? Bought an open-box TV without one? Need a longer cord for wall mounting? Here's everything you need to know about finding the right replacement.
Missing cord: Open-box purchases, secondhand TVs, or lost during relocation
Damaged cord: Fraying, exposed wires, bent prongs, or physical damage
Insufficient length: Standard 4-6 foot cords too short for your setup
Angled connector needed: Wall mounting requires 90-degree angled cord for minimal wall gap
For most Samsung TVs manufactured after 2015:
Connector type: Figure-8 (IEC-60320 C7)
Voltage: 125V (for US use)
Amperage: 10A minimum
Wire gauge: 18 AWG
You do NOT need a Samsung-branded power cord. Any UL-listed Figure-8 cord meeting these specifications works perfectly. The same cord type powers LG, Sony, TCL, and Vizio TVs.
Length | Best For | Price Range |
|---|---|---|
3-6 feet | Standard setup, TV on stand | $8-12 |
10-12 feet | Extended reach, across room routing | $12-18 |
15+ feet | Long runs, complex installations | $15-25 |
90-degree angled | Wall mounting | $10-15 |
Reliable sources:
Amazon: Widest selection, user reviews help identify quality options
Best Buy: In-store availability for immediate needs
Monoprice: Good value for longer cables
Samsung Parts (samsungparts.com): OEM replacement if you prefer original
What to avoid:
Unbranded cables without UL listing
Extremely cheap options (under $5) from unknown sellers
Cables without clearly stated specifications
Follow the same connection steps as the original cord. Verify that:
The connector fits snugly without forcing
The cord routes cleanly without kinking
The standby light illuminates after connection
The TV powers on normally
Wall mounting a Samsung TV creates a clean, modern look - but it also creates power cord challenges. The standard power cord that comes with your TV often isn't ideal for wall mounting scenarios.
Before drilling any holes, plan your power cord routing:
Determine cord path: Will the cord run down the wall visibly, through a raceway, or in-wall?
Measure the distance: From the TV's power port to your nearest outlet
Check outlet position: Is there an outlet directly behind where the TV will hang?
Standard power cords extend straight out from the TV, requiring 2-3 inches of clearance between the TV and wall. 90-degree angled cords solve this problem by turning immediately after the connector, allowing the TV to sit nearly flush.
Look for "L-shaped" or "right angle" Figure-8 cords designed specifically for wall-mounted TVs. These typically add less than 1 inch of depth compared to the connector length of a straight cord.
Cable raceways: Plastic channels that mount to your wall and hide cables inside. Available in various colors to match your wall. No electrical work required.
In-wall cable kits: Allow you to route the power cable through the wall between two mounting plates. Important: Only use cables rated CL2 or CL3 for in-wall installation - standard power cords are not in-wall rated.
Recessed outlet installation: An electrician can install a recessed outlet directly behind the TV, keeping the plug and cord completely hidden. This is the cleanest solution but requires professional electrical work.
The Frame TV's One Connect Box system offers a significant wall mounting advantage: the One Connect Box can be positioned up to 5 meters (16 feet) from the TV with the standard cable, or up to 15 meters (49 feet) with an extended cable.
This means you can place the One Connect Box inside a media cabinet, closet, or another room entirely, with only a single nearly-invisible cable running to the TV. The 2025 Frame Pro takes this further with wireless transmission up to 30 feet.
After completing your wall mount installation, you'll want to optimize your display settings. Our guide to Samsung TV picture settings helps you get the best image quality for your room's lighting conditions.
For connecting a laptop to your wall-mounted TV, check out how to connect MacBook to Samsung TV for wireless and wired options that work with various mounting setups.
No, Samsung TV power cords are not all the same, though most modern models use the same type. The majority of Samsung TVs manufactured since 2015 use the Figure-8 (IEC-60320 C7) power cord - a 2-prong, non-polarized connector. However, some older models use a 3-prong IEC connector, and a few compact models have integrated (non-removable) power cords. Frame TVs and Neo QLED 8K models don't have traditional power cords that connect to the TV; they receive power through the One Connect Box via the Invisible Connection cable.
Yes, you can use a longer power cord for your Samsung TV as long as it matches the correct connector type and electrical specifications. For most Samsung TVs, this means a Figure-8 (C7) connector rated at 125V/10A with 18 AWG wire gauge. Longer cords up to 15-25 feet are available and safe to use. Always purchase UL-listed cords from reputable retailers - avoid extremely cheap unbranded cables that may not meet safety standards.
The power button location varies by Samsung TV model, but it's most commonly found on the back of the TV on the lower-right side when facing the screen. Some models have a single joystick-style button that controls power and navigation. On Frame TVs, the power button is at the bottom center back of the panel. Recent models often use a small multi-function button rather than a dedicated power button. Check your specific model's user manual for the exact location if you can't find it.
If your remote isn't working and you need to control your TV, learn how to pair Samsung TV remote or check our guide on how to use Samsung TV remote for proper button functions and troubleshooting.
If your Samsung TV won't turn on after connecting the power cord, first check whether the red standby light is illuminated. No standby light means the TV isn't receiving power - verify the outlet works, ensure the cord is fully seated in the AC IN port, and try a different outlet. Standby light on but TV unresponsive suggests a remote or mainboard issue - try the physical power button on the TV, replace remote batteries, or perform a power reset by unplugging for 60 seconds while holding the power button for 30 seconds.
A blinking red standby light on a Samsung TV typically indicates a power supply board problem. Two blinks followed by a pause is a common pattern for power-related failures. Do not continue trying to power on the TV, as this could cause additional damage. Try a full power reset first: unplug for 60 seconds, hold the power button 30 seconds while unplugged, wait another 30 seconds, then plug back in. If the blinking continues, professional service is needed - contact Samsung Support or an authorized repair center.
The Samsung Frame TV does not have a traditional power cord that connects directly to the TV panel. Instead, power is delivered through the One Connect Box system. The power cord connects to the One Connect Box, which then transmits power plus audio/video signals to the TV through a single Invisible Connection cable. The One Connect Box is required - the Frame TV cannot function without it.
Exception: The 2025 Frame Pro (LS03FW) uses a Wireless One Connect Box, and the TV itself requires a separate power cord connection. Both the TV and the Wireless One Connect Box need their own power cords.
Yes, you can use an extension cord with your Samsung TV, though Samsung officially recommends connecting directly to a wall outlet when possible. If using an extension cord, choose one rated for at least 10 amps with proper gauge wiring (14 AWG or heavier for longer runs). Avoid daisy-chaining multiple power strips or extension cords together. For surge protection, use a quality surge protector rated for electronics rather than a basic power strip - this protects your TV from voltage spikes while providing the extension you need.
Samsung TV power cords are available from Amazon, Best Buy, Walmart, Samsung Parts (samsungparts.com), and Monoprice. Since most Samsung TVs use the universal Figure-8 (C7) connector, you don't need a Samsung-branded cord - any UL-listed Figure-8 power cord with matching specifications (125V/10A, 18 AWG) will work. Prices typically range from $8-20 depending on length and features (like angled connectors).
For ongoing issues after connecting power, such as Samsung TV channels not working or Samsung TV streaming issues, the problem likely isn't power-related - check our dedicated troubleshooting guides for those specific issues.
Finding your Samsung TV power cord location comes down to knowing your model series. Crystal UHD TVs have the power port on the lower-left back panel. QLED and Neo QLED 4K models typically position it at center-bottom. Frame TVs route power through the One Connect Box rather than directly to the TV.
The power cord itself is almost always a universal Figure-8 (IEC-60320 C7) type - affordable, widely available, and interchangeable with other TV brands. For replacements, any UL-listed cord with matching specifications works perfectly.
When troubleshooting power issues, the red standby light is your diagnostic guide. Solid red means power is reaching the TV. No light indicates a power supply problem. Blinking patterns usually point to internal component failures requiring professional service.
If you've followed this guide and your TV still won't power on, or if you're experiencing issues beyond power connection, our comprehensive Samsung TV troubleshooting guide covers a wider range of problems. For those just getting started with a new TV, the complete Samsung TV setup guide walks through initial configuration step by step.
The power cord location mystery is solved. Now enjoy your Samsung TV.
This guide covers Samsung TV models through 2026, including the latest Neo QLED, QLED, Crystal UHD, Frame, and Frame Pro series. Model-specific details are verified against Samsung official documentation and hands-on testing.
